3″4″ Roof Drain Grating R1300 Series Asme A112.6.4

The R1300 Series Roof Drain Grating (Model LWDG1001) is engineered for high-performance drainage applications, specifically designed to meet the rigorous standards of ASME A112.6.4. Crafted from high-grade ductile iron (ISO1083/JS/500-7), this product offers exceptional durability, load-bearing capacity, and resistance to environmental stress, making it an essential component for commercial, industrial, and municipal roofing drainage systems.

Overview and Design Excellence

Effective roof drainage is critical to maintaining structural integrity and preventing water accumulation-related damages. The LWDG1001 series is meticulously designed to optimize water flow while preventing the ingress of debris, leaves, and other obstructive materials that could compromise the drainage system. Its robust construction ensures long-term operational reliability in diverse weather conditions, ranging from heavy precipitation to intense solar exposure.

Technical Specifications

Key Advantages

• ASME Compliance: Built strictly according to ASME A112.6.4 requirements, ensuring safety and performance compatibility with standard drainage infrastructure.

• Superior Durability: The use of ductile iron provides high tensile strength, ensuring the grating can withstand significant weight and impact without cracking or deformation.

• Corrosion Resistance: Finished with a specialized black bitumen paint, the grating offers excellent protection against rust, oxidation, and chemical agents commonly found in urban and industrial environments.

• Optimized Flow Pattern: The grating design promotes efficient water intake while providing a protective barrier, reducing maintenance frequency for the underlying drain pipes.

• Versatile Application: Suitable for a variety of roofing structures, this unit is the preferred choice for engineers and contractors looking for standardized, reliable hardware.

Installation and Maintenance

The R1300 series is designed for straightforward integration into existing or new drainage assemblies. To ensure optimal service life, we recommend routine inspections to clear any debris that may accumulate on the surface. The black bitumen coating is specifically chosen for its ease of maintenance and ability to be touched up if necessary, ensuring the product remains protected over decades of service.

Why Choose Our Solutions?

As a leading supplier of industrial drainage components, we prioritize quality, compliance, and performance. Our products undergo stringent quality control processes to ensure every piece meets the ISO and ASME benchmarks required for modern infrastructure projects. When you choose our R1300 series gratings, you are choosing a product engineered for reliability, safety, and long-term value.
